PA

FOAM INJECTOR

Foam injector for car-wash brush

The PA foam injector can work with pressures up to 120 bar and flow rates up to 40 l/min. It is designed to be used in combination with the SP9 car-wash brush. The foam injector, through the hole located on the body, allows the air suction when the fluid (water and chemical) passes through the injector itself . The air mixed with water and chemical generates foam. The foam injector is ideal for use in car-wash.

document Download the product sheet

Technical data

Max pressure (bar) 120
Max flow rate (l/min) 40
Body stainless steel

Part numbers

PN INLET OUTLET JIT DELIVERY
1121080025 G 1/4" F Gc 1/4" M Check

MORE INFORMATION

  • Brand: PA
  • Made in Italy
