Emiltec

SCG 304

Aisi 304 stainless steel pneumatic foamer

The SCG 304 is an Aisi 304 stainless steel pneumatic foamer. The foam valve creates a mix of compressed air and chemical product that guarantees the foam effect. The tank, which has a level indicator, is filled with liquid for about 3/4 of its capacity and loaded with compressed air at a maximum of 8 bar: it does not require a continuous connection to the compressed air network. The SCG 304 foamer is equipped with hose and stainless steel lance with foam nozzle. The safety valve is calibrated at 8 bar.

document Download the product sheet

Technical data

Max pressure (bar) 8
Tank Aisi 304 stainless steel

Part numbers

PN TANK (L) MAXIMUM LIQUID CAPACITY (L) HOSE LENGTH (M) LANCE LENGTH (MM) JIT DELIVERY
45SCGX25 24 19 10 750 Check
45SCGX50 50 38 10 750 Check
45SCGX100 100 76 10 750 Check

MORE INFORMATION

  • Brand: Emiltec
  • Product compliant with the PED directive
  • Made in Italy
