Interpump

SERIE 58 (E2)

Interpump plunger pumps - 58 (Evolution 2) series

Interpump plunger pumps of the 58 series are an economical alternative to traditional 200 bar pumps. They are designed to be mounted on compact professional pressure washers and, thanks to the quality of the seals, on self-service car wash modules. They can work with flow rates of up to 18 l/min and pressures of up to 275 bar.

document Download the product sheet

Technical data

Max pressure (bar) 275
Flow rate (l/min) from 7,5 to 18
Manifold brass
PTO male shaft Ø 24 mm
Centering 90/75

Part numbers

PN RPM FLOW RATE (L/MIN) MAX PRESSURE (BAR) MAX POWER (KW) JIT DELIVERY
10E2B2008 1450 7,5 200 2,87
10E2B2808 1450 7,5 275 3,97
10E2B2010 1450 10 200 3,82
10E2B1711 1450 11 170 3,6
10E2B1712 1450 12 170 3,9
10E2B1713 1450 13 170 4,19 Check
10E2B2014 1450 14 200 5,37
10E2B2015 1450 15 200 5,44
10E2B1618 1450 18 160 5,5
10E2C2109 1750 9 210 3,6
10E2C2809 1750 9 275 4,71
10E2C2111 1750 11 210 4,41
10E2C2112 1750 12 210 4,78
10E2C1713 1750 13 170 4,19
10E2C1714 1750 14 170 4,56
10E2C2015 1750 15 200 5,44
10E2C2016 1750 16 200 6,1

MORE INFORMATION

  • Brand: Interpump
  • Available with right or left shaft (please specify in case of order)
  • Made in Italy
