PA

RB 35

RB35 washdown gun

The PA RB35 washing gun can work with flow rates up to 50 l/min and with pressures up to 12 bar. By moving the trigger it is possible to vary the width of the spray cone angle from 0° to 60°. The RB35 is covered by a shockproof plastic shell and 3 stain-proof rings made in soft rubber. The RB35 has a plastic body and it is equipped with a swivel inlet connection. The RB35 is available in two different versions which offer different operating temperature ranges and different chemical compatibilities: these differences are made possible by the use of different seals and internal components. The construction features of the RB35 make this gun suitable for use in the food industry.

document Download the product sheet

Technical data

Max pressure (bar) 12
Max flow rate (l/min) 50
Body plastic

Part numbers

PN WORKING TEMPERATURE (°C) INLET CASING COLOUR TRIGGER COLOUR JIT DELIVERY
1130620000* 50 sw. G 1/2" F Blue Blue Check
1130625000** 80 sw. G 1/2" F Blue Gray Check
*Viton OR
**EPDM OR

MORE INFORMATION

  • Brand: PA
  • Swivel inlet
  • Adjustable cone jet
  • ON/OFF version available (to be used with lance)
  • Made in Italy
